TYTXRV 8-channel DC 24V 30A relay module with fuses

Super fin relæboks der er smart og nem at lave rigtig fin ledningsarbejde med.
Sku: TY0100471 24V - BLACK - With logo

Lagerstatus Bestillingsvare

NOK 1033,67 eksl mva
i h
Send til
*
*
Fraktmetode
Navn
Estimert leveringsdato
Pris
Ingen fraktalternativer

TYTXRV 8-channel DC 24V 30A relay module with fuses

By inserting 24 volts into GND, "Control 1-8" acts as ground control

Rated voltage: 24V

Max contact voltage: DC 30V

Max total current: 50A

Max fuse: 30A (optional with 5A, 10A, 15A, 20A, 25A)

Max consumption: 24V / 0.8A

Durability: 100,000 operations min.

Ambient operating temperature: -20 ~ +85 C degrees

Ambient storage temperature: -20 ~ +80 C degrees

Dimensions: 15.5 x 11 x 6 cm

*
*
*
